High-Voltage Deflection Plate with Resistor Variant 02 for Citronix 3000 and 5000 Series – UPLIMARK UCX-002-2005-002-02

The UPLIMARK High-Voltage Deflection Plate with Resistor Variant 02 is an industrial coding spare part for Citronix 3000 and 5000 Series printheads using the exact Variant 02 high-voltage deflection plate and resistor assembly. It is intended for professional maintenance, repair or component replacement.

What Is the High-Voltage Deflection Plate with Resistor Variant 02?

This item is a high voltage deflection plate with resistor variant 02 identified by UPLIMARK model UCX-002-2005-002-02.

Technical Details

• UPLIMARK model: UCX-002-2005-002-02
• Condition: New compatible replacement part unless otherwise confirmed in the quotation
• Compatible equipment or use: Citronix 3000 and 5000 Series printheads using the exact Variant 02 high-voltage deflection plate and resistor assembly
• Part type: high voltage deflection plate with resistor variant 02
• Included items: One exact source-matched deflection-plate assembly with red lead, resistor, two heat-shrink tubes and two silver fasteners as shown.
• Reference status: Confirm by UPLIMARK model, component photographs, dimensions or an approved sample

Image status: An exact owned high-resolution photograph was transformed into a clean branded ecommerce view. Product geometry and included pieces were structure-reviewed; supplier identity, labels, serial numbers and unverified identifiers were excluded.

Application

Use for professional maintenance, troubleshooting, repair or replacement in a compatible continuous inkjet coding system.

How Do I Confirm Compatibility?

Confirm Variant 02, printer and printhead revision, black plate geometry, resistor color bands and value, lead routing, heat-shrink pieces, fasteners, terminals, voltage requirements and all dimensions before ordering.

Packaging, Condition and Lead Time

Contact UPLIMARK for current stock, packaging, exact included items, supply condition and lead time. Confirm revision, electrical or pressure requirements and installation details before ordering.

Request a Quote

Send the printer model, current part number, clear component photographs, relevant dimensions or connector details and required quantity for compatibility confirmation and a quotation.

Manufacturer names and trademarks are used only to identify equipment compatibility. Unless explicitly stated otherwise, items are supplied as compatible replacements.
